Multi-Functional Machine Tool Bed Casting
多功能机床床身
Rectangular frame machine tool bed with pre-cast…
CORE ADVANTAGES
Rectangular frame for high stiffness
Pre-cast holes and T-grooves
Square support feet for stable levelling
Adaptable pattern for several bed sizes
Attach your 2D/3D drawing on the next step — we reply within 24 business hours.
TECHNICAL DOCUMENTS
TDS / MSDS / material certificates and dimensional inspection reports are provided on request for every order. Please send us an inquiry.
Technical Specs
MATERIAL
Grey Cast Iron HT250
WEIGHT
Approx. 1000 kg per piece
PROCESS
Resin sand casting + aging treatment
TOLERANCE
CT9-CT10 (ISO 8062)
LEAD TIME
5-30 days
MOQ
1 piece (sample), serial quantities on request
SHIPPING
Express delivery
ORIGIN
Qingdao, Shandong, China
CERTIFICATION
ISO 9001 / Material & Dimensional Report
MODEL / SKU
JHD-2303239
Product Introduction
This machine tool bed is a rectangular frame casting in grey cast iron. Regular mounting holes and grooves are distributed over the working surface, side lugs provide connection points for auxiliary units, and square feet at the base spread the load evenly onto the foundation.
The frame construction gives a high stiffness-to-weight ratio, while the closed box sections absorb cutting vibration. Chemical composition is verified by spectrometer on every melt, and hardness is checked after aging so that machinability stays consistent from batch to batch.
The pattern can be adapted to different bed lengths and hole patterns, which makes this a practical base casting for machine builders offering several models on one platform.
Typical Applications
- Machine tool assembly
- Automation frames
- Test benches
