Centrifugal Pump Volute Casing (Rough Casting)
水泵外壳毛坯（蜗壳）
Centrifugal pump volute casing — the spiral flow…
CORE ADVANTAGES
Smooth spiral flow passage
Ribbed shell resists pipe and pressure loads
Controlled machining allowance
Hydrostatic test available
Attach your 2D/3D drawing on the next step — we reply within 24 business hours.
TECHNICAL DOCUMENTS
TDS / MSDS / material certificates and dimensional inspection reports are provided on request for every order. Please send us an inquiry.
Technical Specs
MATERIAL
Grey Cast Iron HT250 / Ductile Iron QT450-10
WEIGHT
Approx. 1000 kg (size dependent)
PROCESS
Resin sand casting + optional machining and hydrostatic test
TOLERANCE
CT9-CT10, machined faces to drawing
LEAD TIME
6-30 days
MOQ
1 piece (sample), serial quantities on request
SHIPPING
Express delivery, Sea freight
ORIGIN
Qingdao, Shandong, China
CERTIFICATION
ISO 9001 / Material & Dimensional Report
MODEL / SKU
JHD-2299926
Product Introduction
The volute is the heart of a centrifugal pump. Its spiral flow passage converts the kinetic energy generated by the rotating impeller into pressure energy, delivering the head the pump is rated for.
On this casting the flanged connection on the left is the suction inlet, the large-diameter cylinder on the right is the discharge, and the internal cavity houses the impeller. External ribs reinforce the shell so it can carry pipe loads and internal pressure without distortion.
Volutes are cast with generous but controlled machining allowance on the flange faces and impeller cavity. We can supply rough castings for your own machining line, or finish-machined and hydrostatically tested parts.
Typical Applications
- Water supply pumps
- Chemical process pumps
- Irrigation and drainage pumps
- Slurry pump casings
